4x2 True 4K HDMI Matrix Switcher with Seamless Switch, Scaler, HDMI Audio Matrix, Auto Sensing, IR / Serial Control, HDCP Management
XQSCM-402
4x2 4K HDMI Matrix Switcher, Seamless Switching, HDMI Audio Extract/ Embed, EDID Emulation, HDCP Setting, IR Serial Control, XQSCM-402
XQSCM-402, 4K HDMI Matrix Switcher, enables the switching of 4 HDMI sources and then delivers the selected video stream to 1~2 HDMI monitors. You can easily control the unit via the front panel push buttons, IR controller, and serial function. Without the hassle of plugging or unplugging cables, these convenient solutions provide seamless switching functionality and a streamlined and efficient HDMI switching experience.
HDMI matrix switcher XQSCM-402 scaling function enables video signals to be evenly displayed on 16:9, 21:9, and 32:9 monitors without image distortion and supports almost all the mainstream monitors on the market, including FHD, QHD, and UHD high-resolution display devices.
Audio Matrix: HDMI Audio and the Extracting & Embedding Function
XQSCM-402, 4K HDMI Matrix Switcher, enables the switching of 4 HDMI sources and then delivers the selected video stream to 1~2 HDMI monitors. You can easily control the unit via the front panel push buttons, IR controller, and serial function. Without the hassle of plugging or unplugging cables, these convenient solutions provide seamless switching functionality and a streamlined and efficient HDMI switching experience.
HDMI matrix switcher XQSCM-402 scaling function enables video signals to be evenly displayed on 16:9, 21:9, and 32:9 monitors without image distortion and supports almost all the mainstream monitors on the market, including FHD, QHD, and UHD high-resolution display devices.
Audio Matrix: HDMI Audio and the Extracting & Embedding Function
The audio de-embedding extracts one HDMI audio, and the audio extracted can be embedded into the other HDMI signal and via the consecutively extracting and embedding process to accomplish the matrix switching. These functions allow users to diversely incorporate the audio signal for more informative contents.
Enables stable EDID transmission and provides enormous preset EDIDs in memory bank
Enables stable EDID transmission and provides enormous preset EDIDs in memory bank
Rextron 4K HDMI matrix switcher unique EDID configuration technology provides 1 auto and 63 EDID preset settings and supports monitors with 16:9, 21:9, and 32:9 aspect ratios. The design keeps unified and continuous video streaming ensuring a smooth video transition between content and prevents video flickering or black-screening issues.
Serial Control (RS-232 & Virtual Com)
Serial Control (RS-232 & Virtual Com)
Built-in RJ-11 serial interface (for DB9 to RJ11 cable) and USB-C Virtual Com port provide users easy and friendly Matrix operation. XQSCM-402 built-in serial interface allows users to control the unit through a PC, serial controller devices or home theater system. Function of switching via serial command on Rextron 4x2 4K HDMI Matrix Switcher is especially designed for industrial control and communication purposes to enhance the functionality of matrix switcher and serial devices management.
- Allows Free Routing among 4 Sources and 2 Displays
- Most Popular Resolutions Supported by the HDMI 2.0 Video Up to 4K@60Hz 4:4:4 ( More than 60 Resolutions )
- Special ATC / Medical Resolutions Supported Such as 2048x2048 / 1536x2048 ...
- Seamless Switch Offers the Best Experience for Digital Signage / Presentation / Commercial / Media Applications
- 3 Flexible Control Methods :
- Push Buttons
- IR Control
- Serial Control
- Auto Sensing Switches the Specific Video Output Either to the Latest Inserted Source or the Highest-Priority Source
- HDMI Audio Matrix Allows the HDMI Audios Freely Routed among 4 Sources
- Serial Control Facilitates Industrial / Media Applications
- HDCP Management Selects the Proper HDCP Version among HDCP 2.2 / 1.4 / Non-HDCP
